Αποσπώμενος μετασχηματιστής ρεύματος 24W

Η STARWELL κατασκευάζει έναν υψηλής ποιότητας αποσπώμενο τροφοδοτικό 24W με εναλλάξιμα βύσματα. Προσφέρει εξαιρετική απόδοση, προσιτή τιμή και παράγεται σε αξιόπιστο εργοστάσιο.

Χαρακτηριστικά:
Universal είσοδος: 100-240VAC 50-60Hz
Ισχύς εξόδου: 24W
Τύπος βύσματος: ΗΠΑ/ΕΕ/ΑΕ/ΗΒ/ΚΝ/ΚΡ αποσπώμενα βύσματα εναλλασσόμενου ρεύματος
Έξοδος: 5V4A, 9V2.5A, 12V2A, 15V1.6A, 18V1.3A 24V1A, 48V0.5A
Πιστοποιητικά: CCC, UL, cUL, CE, FCC, RCM, C-TICK, TUV, UKCA, KC και BIS
Πρότυπο ασφαλείας: IEC62368, IEC60601, IEC1310, IEC61558, IEC60335, IEC61347
Εγγύηση: 3 χρόνια
Χρώμα: μαύρο ή άσπρο προαιρετικό.
Υποδοχή DC: 5,52,5mm, 5,52,1mm, 4,01,7mm, 3,51,35mm, USB C κ.λπ.
Μέγεθος: 75,0x40,5x38,5mm (ΜxΠxΥ)

Αποστολή Ερώτησης

The STARWELL 24W detachable plug power adapter is a versatile and reliable solution for powering your devices. It features interchangeable US/EU/AU/UK/KR/CN plugs, allowing for seamless power connectivity in different countries and regions.
This power adapter complies with international standards such as IEC62368, IEC60601, IEC61558, and IEC61347, making it globally certified for safety and performance. You can trust its quality and reliability.
With output specifications including 5V4A, 9V2.5A, 12V2A, 15V1.6A, 18V1.3A, and 24V1A, this adapter is suitable for a wide range of devices. It can power smartphones, tablets, laptops, monitors, and other electronics that require compatible voltage and current.
The STARWELL 24W detachable plug power adapter finds applications in various places, including homes, offices, schools, and travel settings. It is a reliable companion for charging your devices wherever you go, ensuring convenience and peace of mind.
Choose the STARWELL 24W detachable plug power adapter for its interchangeable plugs, global certifications, and versatile output specifications. It is a dependable power solution for meeting your device charging needs in different environments and situations.

STARWELL 24W interchangeable ac/dc adapter Specification:

Item		24W interchangeable power adapter, 24W detachable plug power adapter, 24W exchangeable power adapter
Type:		Wall mounted power adapter interchangeable plugs
Material		PC Fireproof Material
INPUT		100-240VAC 50/60Hz 0.8A max
Output		5V4A, 9V2.5A, 12V2A, 15V1.6A, 18V1.3A 24V1A, 48V0.5A detachable power adapter Or consult us for specific voltage and current to see if it can be customized or not
Features	Ripple & Noise	<120mV ( <50mV for audio product )
	Efficiency	ERP / CEC-VI standard CoC Tier 2
	Installing	Available for the system of Safety Class I/II
Environment	Operation Temp	-10 ~ +65℃, 10 ~ 95% RH non-condensing
	Storage Temp	-20 ~ +85℃ (Refer to "Derating Curve")
	Storage Humidity	20 ~ 90% RH non-condensing
	Vibration	10 ~ 500Hz, 2G 10min./1cycle, 60min. each along X, Y, Z axes
	Cooling Method	by NTC (natural cooling)
Safety&EMC	Safety Standard	IEC62368, IEC60335, IEC61558, IEC1310, IEC61347
	Safety Approvals	CCC/UL/CE/FCC/CB/KC/KCC/PSE/cUL/TUV/UKCA/NOM/RCM/EAC/ROHS/REACH for more information, please contact us.
	EMC Stardard	EMC EMISSION: EN55032 class B (CISPR32), EN61000-3-2,-3, EAC TP TC 020 EMC IMMUNITY: EN61000-4-2,3,4,5,6,8,11, EN55024; light industry level, criteria A, EAC TP TC 020
	MTBF	5K hrs min. MIL-HDBK-217F (25℃)
Machanicals	DC Connectors	USB-A, USB-C, 5.5x2.1mm, 5.5x2.5mm, 4.0x1.7mm, 3.5x1.35mm and more available
	Dimension	75.0x40.5x38.5mm (LxWxH)
	Packing	145g; 54pcs/14.5Kg/0.056CBM
Application	Advantage	Ultra-small size, light weight, streamline, fully sealed and easy to carry Low-cost design, high reliability, ultrasonic lamination, fireproof housing constant voltage mode, high precision, low noise
Application	usage	sweeping robots, air purifier, led lamps, cctv camera, mini fan, massage chair,massage pillow,etc. facial machines, hair removal device, etc. massage gun, E-bike, scooter, etc.

MODEL LIST

24W DETACHABLE PLUG POWER ADAPTER
POWER	MODEL	INPUT	OUTPUT VOLT	OUTPUT CURRENT	Certificates	PLUG
24W Series	SK02G-050400Z	100-240VAC	5V	4.0A	UL,CE,FCC, RCM,C-TICK, UKCA	interchangeable
	SK02G-090250Z		9V	2.5A
	SK02G-120200Z		12V	2.0A
	SK02G-180133Z		18V	1.33A
	SK02G-240100Z		24V	1.0A
	SK02G-360066Z		36V	0.66A
